QNAP – HOW TO REPAIR RAID5 ARRAY WITH UNRECOVERED READ ERROR (URE) DURING REBUILD

February 24th, 2019 No comments

Tonight I experienced first hand a fear that most QNAP NAS owners have whilst rebuilding a broken drive in a RAID 5 array. You guessed it, the dreaded URE (UNRECOVERED READ ERROR).

# dmesg

[23298.622891] md: md0: recovery done.
[23298.628401] md: Recovering done: md0, degraded=1
[23299.732589] ata6.00: exception Emask 0x0 SAct 0x7fe SErr 0x0 action 0x0
[23299.737963] ata6.00: irq_stat 0x40000008
[23299.743250] ata6.00: failed command: READ FPDMA QUEUED
[23299.748477] ata6.00: cmd 60/00:08:84:d9:44/04:00:57:00:00/40 tag 1 ncq 524288 in
[23299.748481] res 41/40:00:f0:dc:44/00:00:57:00:00/40 Emask 0x409 (media error) <F>
[23299.759028] ata6.00: status: { DRDY ERR }
[23299.764316] ata6.00: error: { UNC }
[23299.782380] ata6.00: configured for UDMA/133
[23299.787537] ata6: EH complete
[23301.855721] ata6.00: exception Emask 0x0 SAct 0x7ff SErr 0x0 action 0x0
[23301.860887] ata6.00: irq_stat 0x40000008
[23301.866252] ata6.00: failed command: READ FPDMA QUEUED
[23301.871320] ata6.00: cmd 60/00:48:84:d9:44/04:00:57:00:00/40 tag 9 ncq 524288 in
[23301.871325] res 41/40:00:ef:dc:44/00:00:57:00:00/40 Emask 0x409 (media error) <F>
[23301.882098] ata6.00: status: { DRDY ERR }
[23301.887228] ata6.00: error: { UNC }
[23306.892039] ata6.00: qc timeout (cmd 0xec)
[23306.897030] ata6.00: failed to IDENTIFY (I/O error, err_mask=0x4)
[23306.902001] ata6.00: revalidation failed (errno=-5)
[23306.906919] ata6: hard resetting link
[23307.371054] ata6: SATA link up 3.0 Gbps (SStatus 123 SControl 320)
[23307.388929] ata6.00: configured for UDMA/133
[23307.393885] ata6: EH complete
[23308.431943] ata6: log page 10h reported inactive tag 0
[23308.436777] ata6.00: exception Emask 0x1 SAct 0x7fe SErr 0x0 action 0x0
[23308.441659] ata6.00: irq_stat 0x40000008
[23308.446492] ata6.00: failed command: READ FPDMA QUEUED
[23308.451684] ata6.00: cmd 60/00:08:84:d9:44/04:00:57:00:00/40 tag 1 ncq 524288 in
[23308.451689] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.461723] ata6.00: status: { DRDY }
[23308.466716] ata6.00: failed command: READ FPDMA QUEUED
[23308.471658] ata6.00: cmd 60/00:10:84:dd:44/03:00:57:00:00/40 tag 2 ncq 393216 in
[23308.471661] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.481539] ata6.00: status: { DRDY }
[23308.486502] ata6.00: failed command: READ FPDMA QUEUED
[23308.491486] ata6.00: cmd 60/08:18:7a:6c:10/00:00:00:00:00/40 tag 3 ncq 4096 in
[23308.491490] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.501645] ata6.00: status: { DRDY }
[23308.506405] ata6.00: failed command: READ FPDMA QUEUED
[23308.511115] ata6.00: cmd 60/08:20:72:6c:10/00:00:00:00:00/40 tag 4 ncq 4096 in
[23308.511119] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.520405] ata6.00: status: { DRDY }
[23308.524995] ata6.00: failed command: READ FPDMA QUEUED
[23308.529534] ata6.00: cmd 60/08:28:6a:6c:10/00:00:00:00:00/40 tag 5 ncq 4096 in
[23308.529538] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.538586] ata6.00: status: { DRDY }
[23308.543067] ata6.00: failed command: READ FPDMA QUEUED
[23308.547584] ata6.00: cmd 60/08:30:62:6c:10/00:00:00:00:00/40 tag 6 ncq 4096 in
[23308.547588] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.556706] ata6.00: status: { DRDY }
[23308.561263] ata6.00: failed command: READ FPDMA QUEUED
[23308.565820] ata6.00: cmd 60/08:38:5a:6c:10/00:00:00:00:00/40 tag 7 ncq 4096 in
[23308.565825] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.574937] ata6.00: status: { DRDY }
[23308.579488] ata6.00: failed command: READ FPDMA QUEUED
[23308.584079] ata6.00: cmd 60/08:40:52:6c:10/00:00:00:00:00/40 tag 8 ncq 4096 in
[23308.584082] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.593387] ata6.00: status: { DRDY }
[23308.597981] ata6.00: failed command: READ FPDMA QUEUED
[23308.602812] ata6.00: cmd 60/08:48:4a:6c:10/00:00:00:00:00/40 tag 9 ncq 4096 in
[23308.602817] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.612334] ata6.00: status: { DRDY }
[23308.616907] ata6.00: failed command: READ FPDMA QUEUED
[23308.621563] ata6.00: cmd 60/08:50:42:6c:10/00:00:00:00:00/40 tag 10 ncq 4096 in
[23308.621567] res 40/00:54:42:6c:10/00:00:00:00:00/40 Emask 0x1 (device error)
[23308.631025] ata6.00: status: { DRDY }
[23308.648602] ata6.00: configured for UDMA/133
[23308.653389] ata6: EH complete
[23310.704908] ata6.00: exception Emask 0x0 SAct 0x3ff SErr 0x0 action 0x0
[23310.709669] ata6.00: irq_stat 0x40000008
[23310.714362] ata6.00: failed command: READ FPDMA QUEUED
[23310.719089] ata6.00: cmd 60/00:48:84:d9:44/04:00:57:00:00/40 tag 9 ncq 524288 in
[23310.719092] res 41/40:00:ef:dc:44/00:00:57:00:00/40 Emask 0x409 (media error) <F>
[23310.728625] ata6.00: status: { DRDY ERR }
[23310.733749] ata6.00: error: { UNC }
[23310.751334] ata6.00: configured for UDMA/133
[23310.756049] ata6: EH complete
[23312.863828] ata6.00: exception Emask 0x0 SAct 0x1 SErr 0x0 action 0x0
[23312.868659] ata6.00: irq_stat 0x40000008
[23312.873247] ata6.00: failed command: READ FPDMA QUEUED
[23312.877828] ata6.00: cmd 60/00:00:84:d9:44/04:00:57:00:00/40 tag 0 ncq 524288 in
[23312.877832] res 41/40:00:ef:dc:44/00:00:57:00:00/40 Emask 0x409 (media error) <F>
[23312.887045] ata6.00: status: { DRDY ERR }
[23312.891653] ata6.00: error: { UNC }
[23312.909053] ata6.00: configured for UDMA/133
[23312.913591] ata6: EH complete
[23314.959481] ata6.00: exception Emask 0x0 SAct 0x1 SErr 0x0 action 0x0
[23314.964017] ata6.00: irq_stat 0x40000008
[23314.968487] ata6.00: failed command: READ FPDMA QUEUED
[23314.972937] ata6.00: cmd 60/00:00:84:d9:44/04:00:57:00:00/40 tag 0 ncq 524288 in
[23314.972941] res 41/40:00:ef:dc:44/00:00:57:00:00/40 Emask 0x409 (media error) <F>
[23314.982330] ata6.00: status: { DRDY ERR }
[23314.986831] ata6.00: error: { UNC }
[23315.004157] ata6.00: configured for UDMA/133
[23315.008655] sd 5:0:0:0: [sda] Unhandled sense code
[23315.013027] sd 5:0:0:0: [sda] Result: hostbyte=DID_OK driverbyte=DRIVER_SENSE
[23315.017468] sd 5:0:0:0: [sda] Sense Key : Medium Error [current] [descriptor]
[23315.021882] Descriptor sense data with sense descriptors (in hex):
[23315.026341] 72 03 11 04 00 00 00 0c 00 0a 80 00 00 00 00 00
[23315.030854] 57 44 dc ef
[23315.035243] sd 5:0:0:0: [sda] Add. Sense: Unrecovered read error – auto reallocate failed
[23315.039729] sd 5:0:0:0: [sda] CDB: Read(10): 28 00 57 44 d9 84 00 04 00 00
[23315.044333] end_request: I/O error, dev sda, sector 1464130799
[23315.048820] md/raid:md0: read error not correctable (sector 1462010216 on sda3).
[23315.053422] raid5: some error occurred in a active device:0 of md0.
[23315.058027] raid5: Keep the raid device active in degraded mode but set readonly.
[23315.062687] md/raid:md0: read error not correctable (sector 1462010224 on sda3).
[23315.067315] raid5: some error occurred in a active device:0 of md0.
[25914.157523] md: ioctl lock interrupted, reason -4, cmd -2142762735

When you encounter a URE during a re-build, most of the advice on many of the forums suggest that the only course of action is to create a new array and restore your data from a backup.

As someone who does not give up that easy, I went looking for an alternative option and found my new best friend. ddrecue.

Using ddrescue, I was able to clone the disk that was having the URE (UNRECOVERED READ ERROR). To begin the process you must first identify the problem disk. Steps are:

  1. You need to ssh / putty into the NAS
  2. Run the command dmesg and locate a line similar to “read error not correctable (sector 1462010224 on sda3)“.
  3. Typically – sda3 = disk1, sdb3 = disk2, sdc3 = disk3, sdd3 = disk 4
  4. Eject the problem disk from the NAS
  5. Download and install SystemRescueCd on a USB stick – see http://www.system-rescue-cd.org/Installing-SystemRescueCd-on-a-USB-stick/
  6. On any computer, install the problem drive and the new replacement drive using SATA connectors.
  7. Configure the computer to boot from USB, plug in the SystemRescueCd on the USB stick and power-on
  8. At the command prompt use fdisk -l to identify your disks – typically /dev/sda and /dev/sdb
  9. To determine which is the source disk, you can use smartctl:|
    smartctl -a /dev/sda
    smartctl -a /dev/sdb
  10. You can also determine drive serial numbers with hdparm:
    hdparm -I /dev/sda
    hdparm -I /dev/sdb
  11. Once the source and destination disks are determined. Use ddrescue to copy the disk:
    ddrescue -f /dev/sda /dev/sdb
    Important Note: In this example /dev/sda is the source and /dev/sdb is the destination.
  12. Once the cloning of the disk completes, replace the problem disk with the new clone and start the RAID array rebuild again.
Categories: QNAP Tags:
